ASUS TUF GAMING Z790-Pro WIFI Motherboard—
$267.20
The Story
| Category | Specification Details |
|---|---|
| Model | TUF GAMING Z790-PRO WIFI |
| CPU Support | Intel® LGA 1700 socket for Intel® Core™ 14th, 13th & 12th Gen, Pentium® Gold and Celeron® Processors; Supports Intel® Turbo Boost Technology 2.0 and Intel® Turbo Boost Max Technology 3.0 |
| Chipset | Intel® Z790 Chipset |
| Memory | 4 x DIMM slots, max. 192GB, DDR5 up to 7800+(OC), Dual channel architecture, Intel® Extreme Memory Profile (XMP), ASUS Enhanced Memory Profile II (AEMP II) |
| Graphics | 1 x DisplayPort (4K@60Hz), 1 x HDMI™ port (4K@60Hz) |
| Expansion Slots | 1 x PCIe 5.0 x16 slot (Intel® Core™ Processors); 1 x PCIe 4.0 x16 slot (x4 mode), 1 x PCIe 4.0 x4 slot, 1 x PCIe 3.0 x16 slot (x1 mode), 1 x PCIe 3.0 x1 slot (Intel® Z790 Chipset) |
| Storage | 4 x M.2 slots (M.2_1 PCIe 4.0 x4; M.2_2 & M.2_3 PCIe 4.0 x4; M.2_4 PCIe 4.0 x4 & SATA modes); 4 x SATA 6Gb/s ports; Supports NVMe & SATA RAID 0/1/5/10 |
| Ethernet | 1 x Intel® 2.5Gb Ethernet, TUF LANGuard |
| Wireless & Bluetooth | Wi-Fi 6E (802.11ax) 2x2, 2.4/5/6GHz bands, Bluetooth® v5.3 |
| Rear USB Ports | 1 x USB 20Gbps (Type-C®), 3 x USB 10Gbps (2 x Type-A + 1 x Type-C®), 4 x USB 5Gbps (Type-A) |
| Front USB Ports | 1 x USB 20Gbps connector (Type-C® with 30W PD Fast-charge), 1 x USB 5Gbps header (2 ports), 2 x USB 2.0 headers (4 ports) |
| Audio | Realtek S1220A 7.1 Surround Sound High Definition Audio CODEC, 120 dB SNR playback, 113 dB SNR recording, up to 32-Bit/192 kHz playback |
| Internal I/O Connectors | 4-pin CPU/Chassis/AIO Fan headers, 24-pin Main Power, 2 x 8-pin +12V Power, 4 x M.2 slots, 4 x SATA ports, Addressable Gen 2 headers, Aura RGB header, Thunderbolt™ (USB4®) header |
| Special Features | ASUS TUF PROTECTION (DIGI+ VRM, ESD Guards, SafeSlot), ASUS Q-Design (Q-Release, Q-Antenna, Q-LED, Q-Latch), Thermal Solution (M.2 heatsinks, VRM heatsink), Pre-mounted I/O shield |
| Software | Armoury Crate, AI Suite 3, AI Overclocking, MyAsus, USB Wattage Watcher, DTS Audio Processing, Norton 360 for Gamers |
| BIOS | 192 (128+64) Mb Flash ROM, UEFI AMI BIOS |
| Operating System | Windows® 11, Windows® 10 64-bit |
| Form Factor | ATX Form Factor (12 inch x 9.6 inch) |
