ASUS TUF GAMING A620AM-PLUS WIFI Motherboard – AM5 Socket – DDR5 7600+ – PCIe 4.0 – Dual M.2 – WiFi 6 – 2.5Gb LAN – Aura Sync – micro-ATX—
$0.02
The Story
ASUS TUF GAMING A620AM-PLUS WIFI Motherboard – AM5 Socket – DDR5 7600+ – PCIe 4.0 – Dual M.2 – WiFi 6 – 2.5Gb LAN – Aura Sync – micro-ATX
| Category | Details |
|---|---|
| Model | ASUS TUF GAMING A620AM-PLUS WIFI |
| CPU Support | AMD AM5 Socket – Ryzen 9000 / 8000 / 7000 Series |
| Chipset | AMD A620A |
| Memory | 4× DDR5 DIMM, Max 256GB, ECC/Non-ECC, Up to 7600+ MT/s (OC), Dual Channel, EXPO & AEMP support |
| Graphics Outputs | 2× DisplayPort (8K@30Hz), 1× HDMI 2.1 (4K@60Hz) |
| Expansion Slots | 1× PCIe 4.0 x16, 1× PCIe 3.0 x1 |
| Storage | 2× M.2 PCIe 4.0 (x4/x2 depending on CPU), 4× SATA 6Gb/s, RAID 0/1/5/10 support |
| Networking | Realtek 2.5Gb Ethernet + TUF LANGuard |
| Wireless & Bluetooth | Wi-Fi 6 (1×1, 802.11ax), Bluetooth 5.3 |
| Rear USB Ports | 2× USB 10Gbps Type-A, 4× USB 2.0 |
| Front USB Ports | 1× USB-C 5Gbps, 2× USB 5Gbps, 4× USB 2.0 |
| Audio | Realtek 7.1 HD Audio, Premium Audio Caps, Audio Shielding |
| Cooling Headers | 1× CPU Fan, 2× Chassis Fan |
| Power Connectors | 24-pin ATX Power, 8-pin CPU Power |
| Special Features | BIOS FlashBack Button, M.2 Q-Latch, SafeSlot Core+, TUF Protection, Aura Sync (ARGB Gen2), Q-LED Core |
| Dimensions | micro-ATX (24.4 × 24.4 cm) |
| Included Accessories | 2× SATA Cables, Wi-Fi Antenna, I/O Shield, M.2 Screws, TUF Gaming Sticker, Quick Start Guide |
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
ASUS TUF GAMING A620AM-PLUS WIFI Motherboard – AM5 Socket – DDR5 7600+ – PCIe 4.0 – Dual M.2 – WiFi 6 – 2.5Gb LAN – Aura Sync – micro-ATX
| Category | Details |
|---|---|
| Model | ASUS TUF GAMING A620AM-PLUS WIFI |
| CPU Support | AMD AM5 Socket – Ryzen 9000 / 8000 / 7000 Series |
| Chipset | AMD A620A |
| Memory | 4× DDR5 DIMM, Max 256GB, ECC/Non-ECC, Up to 7600+ MT/s (OC), Dual Channel, EXPO & AEMP support |
| Graphics Outputs | 2× DisplayPort (8K@30Hz), 1× HDMI 2.1 (4K@60Hz) |
| Expansion Slots | 1× PCIe 4.0 x16, 1× PCIe 3.0 x1 |
| Storage | 2× M.2 PCIe 4.0 (x4/x2 depending on CPU), 4× SATA 6Gb/s, RAID 0/1/5/10 support |
| Networking | Realtek 2.5Gb Ethernet + TUF LANGuard |
| Wireless & Bluetooth | Wi-Fi 6 (1×1, 802.11ax), Bluetooth 5.3 |
| Rear USB Ports | 2× USB 10Gbps Type-A, 4× USB 2.0 |
| Front USB Ports | 1× USB-C 5Gbps, 2× USB 5Gbps, 4× USB 2.0 |
| Audio | Realtek 7.1 HD Audio, Premium Audio Caps, Audio Shielding |
| Cooling Headers | 1× CPU Fan, 2× Chassis Fan |
| Power Connectors | 24-pin ATX Power, 8-pin CPU Power |
| Special Features | BIOS FlashBack Button, M.2 Q-Latch, SafeSlot Core+, TUF Protection, Aura Sync (ARGB Gen2), Q-LED Core |
| Dimensions | micro-ATX (24.4 × 24.4 cm) |
| Included Accessories | 2× SATA Cables, Wi-Fi Antenna, I/O Shield, M.2 Screws, TUF Gaming Sticker, Quick Start Guide |
