The Story
| Category | Specification Details |
|---|---|
| Brand | ARCTIC |
| Power Connector Type | 4-Pin |
| Voltage | 12 Volts |
| Wattage | 4.2 Watts |
| Cooling Method | Water |
| Intel Socket | LGA1851, LGA1700 |
| AMD Socket | AM5, AM4 |
| Radiator Material | Aluminium |
| Cold Plate Material | Copper with Micro Skived Fins |
| Maximum Rotational Speed | 1800 RPM |
| Air Flow Capacity | 56.3 Cubic Feet Per Minute (CFM) |
| Intel Compatibility | LGA1851, LGA1700 |
| AMD Compatibility | AM5, AM4 |
| PI | NNPI | 338 | 309 |
| Thermal Interface Material (TIM) | MX-6 (0.8 g) |
| Warranty | 6 Years |
| Operating Ambient Temperature | 0–40°C |
| Weight | 1840 g |
| All-In-One Connector | 4-Pin PWM Connector |
| Split Connector | 3x 4-Pin PWM Connector |
| Pump Speed | 800–2800 RPM (PWM controlled) |
| Pump Current | Voltage | 0.35 A | 12 V DC |
| Tube Length | 450 mm |
| Tube Diameter | Outer: 12.4 mm, Inner: 6.0 mm |
| Radiator Dimensions | 398 mm (L) x 120 mm (W) x 38 mm (H) |
| VRM Fan Speed | 400–2500 RPM (PWM controlled) |
| VRM Current | Voltage | 0.05 A | 12 V DC |
| Number of Fans | 3x P12 PWM |
| Fan Speed | 200–1800 RPM |
| Fan Air Flow | 56.3 CFM | 95.65 m³/h |
| Static Pressure | 2.20 mmH2 |

Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.

Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.

Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
| Category | Specification Details |
|---|---|
| Brand | ARCTIC |
| Power Connector Type | 4-Pin |
| Voltage | 12 Volts |
| Wattage | 4.2 Watts |
| Cooling Method | Water |
| Intel Socket | LGA1851, LGA1700 |
| AMD Socket | AM5, AM4 |
| Radiator Material | Aluminium |
| Cold Plate Material | Copper with Micro Skived Fins |
| Maximum Rotational Speed | 1800 RPM |
| Air Flow Capacity | 56.3 Cubic Feet Per Minute (CFM) |
| Intel Compatibility | LGA1851, LGA1700 |
| AMD Compatibility | AM5, AM4 |
| PI | NNPI | 338 | 309 |
| Thermal Interface Material (TIM) | MX-6 (0.8 g) |
| Warranty | 6 Years |
| Operating Ambient Temperature | 0–40°C |
| Weight | 1840 g |
| All-In-One Connector | 4-Pin PWM Connector |
| Split Connector | 3x 4-Pin PWM Connector |
| Pump Speed | 800–2800 RPM (PWM controlled) |
| Pump Current | Voltage | 0.35 A | 12 V DC |
| Tube Length | 450 mm |
| Tube Diameter | Outer: 12.4 mm, Inner: 6.0 mm |
| Radiator Dimensions | 398 mm (L) x 120 mm (W) x 38 mm (H) |
| VRM Fan Speed | 400–2500 RPM (PWM controlled) |
| VRM Current | Voltage | 0.05 A | 12 V DC |
| Number of Fans | 3x P12 PWM |
| Fan Speed | 200–1800 RPM |
| Fan Air Flow | 56.3 CFM | 95.65 m³/h |
| Static Pressure | 2.20 mmH2 |
