The Story
| Category | Specification Details |
|---|---|
| Brand | ARCTIC |
| Power Connector Type | 4-Pin |
| Voltage | 12 Volts |
| Wattage | 4.2 Watts |
| Cooling Method | Water Cooling |
| Compatible Devices | Intel Sockets: LGA1851, LGA1700, AMD Sockets: AM5, AM4 |
| Radiator Material | Aluminium |
| Cold Plate Material | Copper with Micro Skived Fins |
| Maximum Rotational Speed | 1700 RPM |
| Air Flow Capacity | 72.8 Cubic Feet Per Minute (CFM) |
| Intel Sockets | LGA1851, LGA1700 |
| AMD Sockets | AM5, AM4 |
| PI | NNPI | 319 | 259 |
| Thermal Interface Material (TIM) | MX-6 (0.8 g) |
| Warranty Duration | 6 Years |
| Ambient Operating Temperature | 0°C — 40°C |
| Product Weight | 1705 g |
| All-In-One Connector Type | 4-Pin PWM |
| Split Connector | 3x 4-Pin PWM Connectors |
| Pump Speed | 800 — 2800 RPM (PWM controlled) |
| Pump Current | Voltage | 0.35 A | 12 V DC |
| Tube Length | 450 mm |
| Tube Diameter | Outer: 12.4 mm, Inner: 6.0 mm |
| Radiator Dimensions | 317 mm (L) x 138 mm (W) x 38 mm (H) |
| VRM Fan Speed | 400 — 2500 RPM (PWM controlled) |
| VRM Current | Voltage | 0.05 A | 12 V DC |
| Number of Fans | 2x P14 PWM |
| Fan Speed | 200 — 1700 RPM |
| Air Flow | 72.80 CFM | 123.76 m³/h |
| Static Pressure | 2.40 mmH2O |
| Bearing Type | Fluid Dynamic Bearing |
| Fan Current | Voltage | 0.12 A | 12 V DC |
| Fan Cable Length | 40 mm |
| Fan Connector | 4-Pin PWM Connector |
| Packaging Dimensions | Width: 170 mm, Height: 155 mm, Length: 335 mm |
| Packaging Weight | 2.233 kg |
| EAN | 4895213704472 |
| UPC | 840033402248 |

Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.

Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.

Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
| Category | Specification Details |
|---|---|
| Brand | ARCTIC |
| Power Connector Type | 4-Pin |
| Voltage | 12 Volts |
| Wattage | 4.2 Watts |
| Cooling Method | Water Cooling |
| Compatible Devices | Intel Sockets: LGA1851, LGA1700, AMD Sockets: AM5, AM4 |
| Radiator Material | Aluminium |
| Cold Plate Material | Copper with Micro Skived Fins |
| Maximum Rotational Speed | 1700 RPM |
| Air Flow Capacity | 72.8 Cubic Feet Per Minute (CFM) |
| Intel Sockets | LGA1851, LGA1700 |
| AMD Sockets | AM5, AM4 |
| PI | NNPI | 319 | 259 |
| Thermal Interface Material (TIM) | MX-6 (0.8 g) |
| Warranty Duration | 6 Years |
| Ambient Operating Temperature | 0°C — 40°C |
| Product Weight | 1705 g |
| All-In-One Connector Type | 4-Pin PWM |
| Split Connector | 3x 4-Pin PWM Connectors |
| Pump Speed | 800 — 2800 RPM (PWM controlled) |
| Pump Current | Voltage | 0.35 A | 12 V DC |
| Tube Length | 450 mm |
| Tube Diameter | Outer: 12.4 mm, Inner: 6.0 mm |
| Radiator Dimensions | 317 mm (L) x 138 mm (W) x 38 mm (H) |
| VRM Fan Speed | 400 — 2500 RPM (PWM controlled) |
| VRM Current | Voltage | 0.05 A | 12 V DC |
| Number of Fans | 2x P14 PWM |
| Fan Speed | 200 — 1700 RPM |
| Air Flow | 72.80 CFM | 123.76 m³/h |
| Static Pressure | 2.40 mmH2O |
| Bearing Type | Fluid Dynamic Bearing |
| Fan Current | Voltage | 0.12 A | 12 V DC |
| Fan Cable Length | 40 mm |
| Fan Connector | 4-Pin PWM Connector |
| Packaging Dimensions | Width: 170 mm, Height: 155 mm, Length: 335 mm |
| Packaging Weight | 2.233 kg |
| EAN | 4895213704472 |
| UPC | 840033402248 |
