Select COLOR
From $104.95
Antec Vortex 360mm ARGB Liquid CPU Cooler – Advanced Cooling & RGB Lighting—
$104.95
The Story
| Category | Specification Details |
|---|---|
| Radiator Dimensions | 397 × 120 × 27 mm |
| Radiator Material | Aluminum |
| TDP Rating | 280W (Vortex360) |
| Pump Dimensions | Ø67 × 48.5 mm |
| Pump Rated Voltage | DC 12V |
| Pump Min. Startup Voltage | ≥ 5.0 V |
| Pump Speed | 2800 ±10% RPM |
| Pump Rated Current | 0.25 ±20% A |
| Pump Power Consumption | 3.0 W |
| Pump Flow Rate | ≥ 1300 mL/min |
| Water Pressure | 1.4 m |
| Pump Noise Level | ≤ 28 dB(A) |
| Pump Lifespan | 40,000 hours |
| Pump Connectors | PUMP: 3-pin | LED: 3-pin |
| Operating Temperature | -10°C to +60°C |
| Fan Type | PWM Fan |
| Fan Dimensions | 120 × 120 × 25 mm |
| Fan Bearing Type | Hydraulic Bearing |
| Fan LED Type | Addressable RGB |
| Fan Speed | 600 ±200 ~ 2000 ±10% RPM |
| Fan Airflow (Max.) | 57.93 CFM |
| Fan Air Pressure (Max.) | 2.11 mmH₂O |
| Fan Noise Level | 31.24 dB(A) |
| Fan Rated Voltage | Fan: DC 12V | LED: DC 5V |
| Fan Operating Voltage | Fan: DC 6.0–13.8V | LED: DC 4.5–5.5V |
| Fan Rated Current | Fan: ≤ 0.21 A | LED: ≤ 0.58 A |
| Fan Lifespan | 40,000 hours |
| Fan Connectors | FAN: 4-pin PWM | LED: 3-pin |
| Intel Compatibility | LGA 115X / 1200 / 1700 / 20XX |
| AMD Compatibility | AM3 / AM4 / AM5 / TR4 |
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
| Category | Specification Details |
|---|---|
| Radiator Dimensions | 397 × 120 × 27 mm |
| Radiator Material | Aluminum |
| TDP Rating | 280W (Vortex360) |
| Pump Dimensions | Ø67 × 48.5 mm |
| Pump Rated Voltage | DC 12V |
| Pump Min. Startup Voltage | ≥ 5.0 V |
| Pump Speed | 2800 ±10% RPM |
| Pump Rated Current | 0.25 ±20% A |
| Pump Power Consumption | 3.0 W |
| Pump Flow Rate | ≥ 1300 mL/min |
| Water Pressure | 1.4 m |
| Pump Noise Level | ≤ 28 dB(A) |
| Pump Lifespan | 40,000 hours |
| Pump Connectors | PUMP: 3-pin | LED: 3-pin |
| Operating Temperature | -10°C to +60°C |
| Fan Type | PWM Fan |
| Fan Dimensions | 120 × 120 × 25 mm |
| Fan Bearing Type | Hydraulic Bearing |
| Fan LED Type | Addressable RGB |
| Fan Speed | 600 ±200 ~ 2000 ±10% RPM |
| Fan Airflow (Max.) | 57.93 CFM |
| Fan Air Pressure (Max.) | 2.11 mmH₂O |
| Fan Noise Level | 31.24 dB(A) |
| Fan Rated Voltage | Fan: DC 12V | LED: DC 5V |
| Fan Operating Voltage | Fan: DC 6.0–13.8V | LED: DC 4.5–5.5V |
| Fan Rated Current | Fan: ≤ 0.21 A | LED: ≤ 0.58 A |
| Fan Lifespan | 40,000 hours |
| Fan Connectors | FAN: 4-pin PWM | LED: 3-pin |
| Intel Compatibility | LGA 115X / 1200 / 1700 / 20XX |
| AMD Compatibility | AM3 / AM4 / AM5 / TR4 |
