ROG Ally X (2025) – Handheld Gaming Console with Ryzen Z1 Extreme, 16GB RAM, 512GB SSD, FHD 120HZ

ROG Ally X (2025) – Handheld Gaming Console with Ryzen Z1 Extreme, 16GB RAM, 512GB SSD, FHD120HZ

• Marketing Name: ROG Ally X

• Sales Model Name: RC73YA-NH165W

• Part No: 90NV00G1-M000V0

• Color: White

• Dimensions: 28.9 x 11.3 x 2.50 ~ 5.00 cm (11.38" x 4.45" x 0.98" ~ 1.97")

• Weight: 639g (1.41 lbs)

Performance & Display

• Processor: AMD Ryzen™ Z2 A (2.8GHz, up to 3.8GHz, 4C/8T)

• GPU: AMD Radeon™ Graphics (RDNA™ 3, 12 CUs, up to 2.7GHz, 8.6 TFLOPS)

• Display: 7" FHD (1920×1080), 120Hz, IPS-level

• Glass: Gorilla® Glass DXC + Victus™

• Brightness / Contrast: 500 nits / 1200:1

• Color Gamut: 72% NTSC, 100% sRGB, 75.35% Adobe

• Other: FreeSync Premium, Glossy, Wide Viewing Angles (85° each side)

Memory & Storage

• RAM: 16GB LPDDR5X (dual channel, 6400MT/s)

• Storage: 512GB PCIe 4.0 NVMe M.2 2280 SSD

• Expansion: 1x M.2 slot

Connectivity

• Wi-Fi: Wi-Fi 6E (802.11ax, Tri-band)

• Bluetooth: 5.2

• Ports:

  • 2x USB-C 3.2 Gen 2 (DisplayPort + Power Delivery)

  • 1x microSD UHS-II slot

  • 1x 3.5mm Combo Audio Jack

Audio & Features

• Speakers: Dual speakers with Smart Amp

• Audio Tech: Dolby Atmos, Hi-Res certification, AI noise-canceling

• Mic: Built-in array mic

• OS: Windows 11 Home

• Xbox Game Pass: 3 months Ultimate included

• Security: Fingerprint sensor, Microsoft Pluton chip

Battery & Power

• Battery: 60Wh, 4-cell Li-ion

• Charger: USB-C 65W adapter (20V, 3.25A)

Controls

• ABXY buttons, D-pad

• 2 analog thumbsticks

• L/R bumpers + Hall Effect triggers

• Armoury Crate + Command Center buttons

• View/Menu buttons

• 2 assignable grip buttons

• HD haptics, 6-Axis IMU
