$206.13
Power Supply Antec SIGNATURE SP1300W 80+ Platinum Full Modular—
$206.13
The Story
Power Supply Antec SIGNATURE SP1300W 80+ Platinum Full Modular
FDB 135mm
Zero RPM Mode
The Zero RPM fan mode further ensures a longer-lasting and quieter system by using thermal sensors to activate the fan only when you need it.
100% Top-Grade Japanese Capacitors
Achieve unprecedented tight voltage regulation & low ripple
& noise to maximize your system’s performance.
PhaseWavetm Design
A server-class full-bridge LLC design with a synchronous rectification based on a DC-DC topology.
Full Modular
Cable Management
Enables users to use only the cables which are needed and help clear out excess cables that can obstruct and reduce airflow.
Product Name |
SP1300 Platinum |
Model Name |
X8000A506-18 |
Type |
ATX |
Modular |
Fully |
Dimension (W x L x H) |
150 x 170 x 86mm |
Warranty |
10 years |
Input Voltage |
100-240 |
Input Current |
15A ~ 7.5A |
Input Frequency Range |
47Hz ~ 63Hz |
PFC |
APFCPFC at half / full load:>0.95 at AC 110v 60Hz(typical)>0.90 at AC 230v 50Hz(typical) |
Power Good Signal |
100 ~ 500mS |
Efficiency |
At 20% / 50% / 100% load AC 115V internal,the power efficiency should be at least 90% / 92% / 89%. |
Protection |
OCP / OVP / UVP / SCP / OPP / OTP / SIP / NLO |
Output Capacity |
1300W |
Operation Temperature |
0 ~ 40°C |
Regulatory |
cTUVus / TUV / CB [IEC62368 Compliant] / CE /FCC / BSMI / 3C / KC / RCM |
Fan |
135 x 135 x 25(mm) FDB Silent Fan |
Certifications |
80 Plus Platinum |
Connector |
1 x MB 24(20+4) Pin |
2 x 8(4+4) Pin EPS 12V |
|
12 x 8(6+2) Pin PCI-E |
|
14 x SATA |
|
5 x Molex |
|
1 x FDD |
|
UPC# |
0-761345-11705-0 SP13000-761345-11706-7 SP1300 AU0-761345-11707-4 SP1300 EC0-761345-11708-1 SP1300 GB0-761345-11709-8 SP1300 JP |
Net Weight |
2.12 Kgs |
Gross Weight |
4.05 Kgs |
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
Power Supply Antec SIGNATURE SP1300W 80+ Platinum Full Modular
FDB 135mm
Silent Fan
Featuring whisper-quiet, fluid dynamic bearing 135mm fan provides high airflow with durability and longevity.
Zero RPM Mode
The Zero RPM fan mode further ensures a longer-lasting and quieter system by using thermal sensors to activate the fan only when you need it.
100% Top-Grade Japanese Capacitors
Achieve unprecedented tight voltage regulation & low ripple
& noise to maximize your system’s performance.
PhaseWavetm Design
A server-class full-bridge LLC design with a synchronous rectification based on a DC-DC topology.
Full Modular
Cable Management
Enables users to use only the cables which are needed and help clear out excess cables that can obstruct and reduce airflow.
Product Name |
SP1300 Platinum |
Model Name |
X8000A506-18 |
Type |
ATX |
Modular |
Fully |
Dimension (W x L x H) |
150 x 170 x 86mm |
Warranty |
10 years |
Input Voltage |
100-240 |
Input Current |
15A ~ 7.5A |
Input Frequency Range |
47Hz ~ 63Hz |
PFC |
APFCPFC at half / full load:>0.95 at AC 110v 60Hz(typical)>0.90 at AC 230v 50Hz(typical) |
Power Good Signal |
100 ~ 500mS |
Efficiency |
At 20% / 50% / 100% load AC 115V internal,the power efficiency should be at least 90% / 92% / 89%. |
Protection |
OCP / OVP / UVP / SCP / OPP / OTP / SIP / NLO |
Output Capacity |
1300W |
Operation Temperature |
0 ~ 40°C |
Regulatory |
cTUVus / TUV / CB [IEC62368 Compliant] / CE /FCC / BSMI / 3C / KC / RCM |
Fan |
135 x 135 x 25(mm) FDB Silent Fan |
Certifications |
80 Plus Platinum |
Connector |
1 x MB 24(20+4) Pin |
2 x 8(4+4) Pin EPS 12V |
|
12 x 8(6+2) Pin PCI-E |
|
14 x SATA |
|
5 x Molex |
|
1 x FDD |
|
UPC# |
0-761345-11705-0 SP13000-761345-11706-7 SP1300 AU0-761345-11707-4 SP1300 EC0-761345-11708-1 SP1300 GB0-761345-11709-8 SP1300 JP |
Net Weight |
2.12 Kgs |
Gross Weight |
4.05 Kgs |
