D-Link DAP-2680 nuclias connect wireless AC1750 Wave 2 Dual-Band PoE Access Point

Device Interfaces

• IEEE 802.11a/b/g/n/ac¹ Wave 2 wireless interface

• 1 x Gigabit PoE-capable LAN port

Standards

• IEEE 802.11a/b/g/n/ac¹

• IEEE 802.3i/u/ab

• IEEE 802.3az Energy-Efficient Ethernet (EEE)

• IEEE 802.3at Power over Ethernet

Antennas

• 3 x internal dual-band antennas

• 3.6 dBi at 2.4 GHz, 4.2 dBi at 5 GHz

Operating Frequency

• 2.4 GHz band: 2.4 to 2.4835 GHz

• 5 GHz band: 5.15 to 5.35 GHz, 5.47 to 5.85 GHz

Maximum Output Power

• 26.5 dbm for 2.4GHz

• 26.5 dbm for 5GHz

Data Signal Rate

• 2.4 GHz: Up to 450 Mbps¹

• 5 GHz: Up to 1300 Mbps¹

Security

• WPA-Personal

• WPA-Enterprise

• WPA2-Personal

• WPA2-Enterprise

• WEP 64/128-bit encryption

• SSID broadcast disable

• MAC address access control

• Network Access Protection (NAP)

• Internal RADIUS server

Operating Modes

• Access Point (AP)

• WDS with AP

• WDS/Bridge (No AP Broadcast)

• Wireless Client

Network Management

• Telnet

• Secure Telnet (SSH)

• Web (HTTP)

• Secure Socket Layer (SSL)

• Traffic control

• SNMP v1/v2c/v3

• Nuclias Connect Software

• Nuclias Connect Hub⁵

LEDs

Power/status

Dimensions

190 x 190 x 44.8 mm (7.48 x 7.48 x 1.76 in)

Weight

580 g (1.28 lbs) without mounting base

636.5 g (1.40 lbs) with mounting base

Power Supply

External power adapter: 12 V/2 A (not included)

IEEE 802.3at PoE

Maximum Power Consumption

17.53 Watts

Temperature

Operating: 0 to 40 °C (32 to 104 °F)

Storage: -20 to 65 °C (-4 to 149 °F)

Humidity

Operating: 10% to 90% non-condensing

Storage: 5% to 95% non-condensing

Meantime Between Failure (MTBF)

> 30,000 hours

Certifications

FCC, CE⁴, UL

Maximum APs per Installation⁶

• 1,000 (large scale installations)

• 100(small scale installaions)

WLAN Management Features

• AP grouping

• Multi-tenancy

• Visualised topology

• NAT pass-through

• Setup wizard

• AP discovery (layer 2 and layer 3)

• Report system

Guest Portal

Captive portal

Authentication Method

• Local

• POP3

• RADIUS

• LDAP

• Voucher

Hotspot Features

• Built-in support for voucher-based authentication

• Built-in hotspot manager for voucher creation and guest management

• Rate limiting and bandwidth control for guest and hotspot portal

RF Management and Control

• Auto Output Power Control

• Auto Channel

• Self-healing around failed APs

Multiple SSIDs per Radio(AP)

8

Advanced Wireless Features

• Band steering

• L2 roaming

• Bandwidth optimisation

• Airtime fairness

Management Interface

Web-based user interface (HTTPS)

Scheduling

• Firmware update

• Configuration update
