Select COLOR
From $104.97
Cooler Master Elite 600 ARGB Case 4 Fans + XPG 700W 80+ Bronze Power Supply Bundle—
$104.97
The Story
| Category | Specification Details |
|---|---|
| Product Name | Elite 600 |
| Color(s) | Black / White |
| Model Number | Black: E600-KGNN-S02, White: E600-WGNN-S02 |
| Materials - Exterior | SGPCC Steel |
| Materials - Side panel (Right / Left) | Steel / Tempered Glass |
| Dimensions (L x W x H) | 445 x 285 x 410mm(Incl. Protrusions), 445 x 285 x 400 mm(Excl. Protrusions) |
| Volume | 50.73 L |
| Motherboard Support | Mini-ITX, Mini-DTX, Micro-ATX, ATX |
| Power Supply Support | ATX |
| Expansion Slots | 7 |
| 5.25" Drive Bays | N/A |
| 3.5" Drive Bays | 1 |
| 2.5" / 3.5" Drive Bays (Combo) | 1 |
| 2.5" Drive Bays | 2 |
| I/O Panel | 2x USB 3.1 Gen 1 Type-A, 1x USB 3.2 Gen 2 Type-C |
| I/O Panel - Audio In / Out | 1x 3.5mm Headset Jack (Audio+Mic) |
| Pre-installed Fans - Bottom | 3x 120mm ARGB reverse version |
| Pre-installed Fans - Rear | 1x 120mm ARGB |
| Pre-installed Fans - Side Mount | 3x 120mm ARGB reverse version |
| Fan Support - Bottom | 3x 120mm |
| Fan Support - Top | 3x 120mm / 2x 140mm |
| Fan Support - Rear | 1x 120mm |
| Fan Support - Side | 3x 120mm / 2x 140mm |
| Radiator Support - Bottom | 240 / 360mm |
| Radiator Support - Top | 240 / 280 / 360 mm |
| Radiator Support - Rear | 120mm |
| Radiator Support - Side | 240 / 280 mm |
| Dust Filters | Top, Bottom, Right Side Panel |
| Clearance - CPU Cooler | 160mm |
| Clearance - PSU | 240mm |
| Clearances - Graphics Card | L: 425 mm (incl. power connector), H: 160 mm (incl. power connector) |
| Cable Routing - Behind MB Tray | 11mm |
| Series | Elite Series |
| Size | Mid Tower |
| PSU Dimensions (L x W x H) | 140 x 150 x 86mm |
| 80 Plus Rating | BRONZE |
| ATX Version | ATX 2.52 |
| Protections | OVP / OPP / SCP / UVP / OTP / SIP |
| Certification | CB, CE, FCC, TUV, cTUVus, BSMI, CCC, NOM, FCC IC, UKCA, EAC, RCM |
| PFC | > 0.99 @ Typical load |
| Input Voltage | 100-240V, 47~63Hz |
| Input Current | 9A - 10A |
| Input Frequency | 47 - 63Hz |
| DC Output Voltage | +5V | +3.3V | +12V | -12V | +5Vsb |
| Total Output | 700W: +5V: 17A, +3.3V:19A, +12V:54A, -12V:0.3A, +5Vsb:2.5A | 600W: +5V: 17A, +3.3V:19A, +12V:46A, -12V:0.3A, +5Vsb:2.5A |
| Power Excursion | Total:700W +5V/+3.3V:110W, +12V:648W, -12V:3.6W, +5Vsb:12.5W | Total:600W +5V/+3.3V:110W, +12V:552W, -12V:3.6W, +5Vsb:12.5W |
| Operating Temperature | 0~40°C |
| Fan Size | 120mm |
| Fan Bearing | Sleeve Bearing Fan |
| Fan Speed | 2400 ± 10% RPM |
| MTBF | >100,000 hours @ 25°C |
| ATX 24 Pin Connector | 1 |
| EPS 8 (4+4) Pin Connector | 2 |
| Molex 4 Pin Connector | 2 |
| Weight | 700W:1526.6g |
