ASUS ROG STRIX X870E-H GAMING WIFI7 HATSUNE MIKU EDITION – AM5, PCIe 5.0, USB4, DDR5 8000+, 4x M.2, 5Gb LAN, Wi-Fi 7, Aura Sync, ATX—
$0.02
The Story
ASUS ROG STRIX X870E-H GAMING WIFI7 HATSUNE MIKU EDITION – AM5, PCIe 5.0, USB4, DDR5 8000+, 4x M.2, 5Gb LAN, Wi-Fi 7, Aura Sync, ATX
Category |
Details |
|---|
Model |
ROG STRIX X870E-H GAMING WIFI7 HATSUNE MIKU EDITION |
CPU Support |
AMD Ryzen 9000 / 8000 / 7000 Series – AM5 |
Chipset |
AMD X870E |
Memory |
4× DDR5 DIMM / Up to 256GB / Up to 8000+ MT/s (OC) / EXPO / AEMP / On-Die ECC |
Graphics Outputs |
1× HDMI 2.1 (4K@60Hz), 2× USB4 Type-C (DisplayPort 1.4a up to 4K@60Hz) |
PCIe Slots |
1× PCIe 5.0 x16, 1× PCIe 4.0 x16 (x4), depending on CPU |
Storage |
4× M.2 (PCIe 5.0 / 4.0), 4× SATA 6Gb/s |
RAID Support |
RAID 0/1/5/10 (Ryzen 9000), RAID 0/1 (Ryzen 8000), RAID 0/1/10 (Ryzen 7000) |
Ethernet |
Realtek 5Gb LAN + ASUS LANGuard |
Wireless |
Wi-Fi 7 (MT7925), 2×2, 2.4/5/6GHz, Bluetooth 5.4 |
Rear USB Ports |
14 total: 2× USB4 40Gbps (Type-C), 4× USB 10Gbps, 6× USB 5Gbps, 2× USB 2.0 |
Front USB |
1× USB 20Gbps Type-C, 1× USB 5Gbps header, 2× USB 2.0 headers |
Audio |
Realtek ALC1220P, SupremeFX, Savitech AMP, Optical S/PDIF |
Cooling Headers |
1× CPU Fan, 1× CPU OPT, 1× AIO Pump, 5× Chassis Fans |
Power Connectors |
24-pin ATX, 2× 8-pin CPU |
RGB Headers |
3× Addressable RGB Gen 2 |
Special Features |
Miku-themed design, Miku stickers, Miku phone stand, PCIe Q-Release, M.2 Q-Latch, Pre-mounted I/O Shield, AI Cooling II, BIOS FlashBack |
Back Panel Ports |
USB4 x2, USB 10Gbps x4, USB 5Gbps x6, USB 2.0 x2, HDMI, 5Gb LAN, Audio jacks, Optical S/PDIF, BIOS FlashBack, Clear CMOS |
Included Accessories |
SATA cables, WiFi antenna, M.2 Q-Latch, Miku Phone Stand, Miku Stickers, PCIe-to-front USB card, M.2 rubbers |
OS Support |
Windows 11 |
Form Factor |
ATX – 30.5 × 24.4 cm |
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Details & Craftsmanship
Every detail has been carefully considered to bring you the perfect product.
Description
ASUS ROG STRIX X870E-H GAMING WIFI7 HATSUNE MIKU EDITION – AM5, PCIe 5.0, USB4, DDR5 8000+, 4x M.2, 5Gb LAN, Wi-Fi 7, Aura Sync, ATX
Category |
Details |
|---|
Model |
ROG STRIX X870E-H GAMING WIFI7 HATSUNE MIKU EDITION |
CPU Support |
AMD Ryzen 9000 / 8000 / 7000 Series – AM5 |
Chipset |
AMD X870E |
Memory |
4× DDR5 DIMM / Up to 256GB / Up to 8000+ MT/s (OC) / EXPO / AEMP / On-Die ECC |
Graphics Outputs |
1× HDMI 2.1 (4K@60Hz), 2× USB4 Type-C (DisplayPort 1.4a up to 4K@60Hz) |
PCIe Slots |
1× PCIe 5.0 x16, 1× PCIe 4.0 x16 (x4), depending on CPU |
Storage |
4× M.2 (PCIe 5.0 / 4.0), 4× SATA 6Gb/s |
RAID Support |
RAID 0/1/5/10 (Ryzen 9000), RAID 0/1 (Ryzen 8000), RAID 0/1/10 (Ryzen 7000) |
Ethernet |
Realtek 5Gb LAN + ASUS LANGuard |
Wireless |
Wi-Fi 7 (MT7925), 2×2, 2.4/5/6GHz, Bluetooth 5.4 |
Rear USB Ports |
14 total: 2× USB4 40Gbps (Type-C), 4× USB 10Gbps, 6× USB 5Gbps, 2× USB 2.0 |
Front USB |
1× USB 20Gbps Type-C, 1× USB 5Gbps header, 2× USB 2.0 headers |
Audio |
Realtek ALC1220P, SupremeFX, Savitech AMP, Optical S/PDIF |
Cooling Headers |
1× CPU Fan, 1× CPU OPT, 1× AIO Pump, 5× Chassis Fans |
Power Connectors |
24-pin ATX, 2× 8-pin CPU |
RGB Headers |
3× Addressable RGB Gen 2 |
Special Features |
Miku-themed design, Miku stickers, Miku phone stand, PCIe Q-Release, M.2 Q-Latch, Pre-mounted I/O Shield, AI Cooling II, BIOS FlashBack |
Back Panel Ports |
USB4 x2, USB 10Gbps x4, USB 5Gbps x6, USB 2.0 x2, HDMI, 5Gb LAN, Audio jacks, Optical S/PDIF, BIOS FlashBack, Clear CMOS |
Included Accessories |
SATA cables, WiFi antenna, M.2 Q-Latch, Miku Phone Stand, Miku Stickers, PCIe-to-front USB card, M.2 rubbers |
OS Support |
Windows 11 |
Form Factor |
ATX – 30.5 × 24.4 cm |
